Setting Up Your Kubernetes Cluster with EC2 Instances or DigitalOcean Droplets

A step-by-step guide to setting up a Kubernetes cluster using EC2 instances or DigitalOcean droplets with Kind, Minikube, or Kubeadm.

December 28, 2024
5 min read

If you're venturing into Kubernetes land, the first step is setting up a virtual machine (VM) in the cloud. You can use either AWS EC2 Instances or DigitalOcean Droplets.

What Are EC2 Instances and Droplets?#

Think of these as your personal cloud-based computers. With them, you'll configure the environment needed to deploy and run your Kubernetes cluster.

AWS EC2#

  1. Sign Up: Create an AWS account
  2. Launch Instance: Set up an EC2 instance and follow the instructions to connect
  3. Connect: Use AWS's guide to SSH into your instance

DigitalOcean Droplets#

  1. Sign Up: Create a DigitalOcean account
  2. Create Droplet: Spin up a droplet with the specs you need
  3. Connect: Access the droplet using the web terminal provided

Installing Kind and Docker#

Step 1: Create a Shell Script#

Use vim to create the file:

Code
vim kind_install.sh

Paste this script into the file:

Code
#!/bin/bash

[ $(uname -m) = x86_64 ] && curl -Lo ./kind https://kind.sigs.k8s.io/dl/v0.20.0/kind-linux-amd64
chmod +x ./kind
sudo cp ./kind /usr/local/bin/kind

VERSION="v1.30.0"
URL="https://dl.k8s.io/release/${VERSION}/bin/linux/amd64/kubectl"
INSTALL_DIR="/usr/local/bin"

curl -LO "$URL"
chmod +x kubectl
sudo mv kubectl $INSTALL_DIR/
kubectl version --client

rm -f kubectl
rm -rf kind

echo "kind & kubectl installation complete."

Make it executable and run:

Code
chmod 777 kind_install.sh
./kind_install.sh

Step 2: Install Docker#

Update packages and install Docker:

Code
sudo apt-get update
sudo apt-get install docker.io

Enable Docker at boot and set permissions:

Code
sudo systemctl enable --now docker
sudo usermod -aG docker $USER && newgrp docker

Creating a Kind Cluster#

Create a configuration file:

Code
vim config.yml

Add this configuration:

Code
kind: Cluster
apiVersion: kind.x-k8s.io/v1alpha4

nodes:
- role: control-plane
  image: kindest/node:v1.28.0
- role: worker
  image: kindest/node:v1.28.0
- role: worker
  image: kindest/node:v1.28.0
- role: worker
  image: kindest/node:v1.28.0
  extraPortMappings:
  - containerPort: 80
    hostPort: 80
    protocol: TCP
  - containerPort: 443
    hostPort: 443
    protocol: TCP

Create and verify the cluster:

Code
kind create cluster --name=<cluster_name> --config=config.yml
kubectl get nodes

Installing and Setting Up Cluster with Minikube#

Install dependencies:

Code
sudo apt install -y curl wget apt-transport-https

Download and install Minikube:

Code
wget https://storage.googleapis.com/minikube/releases/latest/minikube-linux-amd64
chmod +x minikube-linux-amd64
sudo mv minikube-linux-amd64 /usr/local/bin/minikube

Verify and start:

Code
minikube version
minikube start --driver=docker --vm=true

Note: Use --vm=true only for EC2 instances. On Droplets, you can skip it. Use either Kind or Minikube at a time; mixing both may cause errors!

Kubeadm: Setting Up a Production Cluster#

For production environments, Kubeadm is your best friend. Let's set up a cluster with a control plane (master) and a worker node across two VMs.

Prepping AWS#

Step 1: Select the worker-k8s Instance from the EC2 Dashboard

Step 2: Navigate to Security Groups under Network & Security

Step 3: Create a new Security Group with these Inbound Rules:

TypeProtocolPortSource
SSHTCP22Your IP or 0.0.0.0/0
Custom TCPTCP6443Master node IP

Step 4: Assign the security group to both instances and launch them

Prepping DigitalOcean#

  1. Create two droplets: master-k8s and worker-k8s with the same SSH key
  2. Create a firewall with inbound rules for ports 6443 and 22 (TCP/UDP)
  3. Assign the firewall to both droplets

Kubernetes Cluster Setup Commands#

Commands for Both Master and Worker Nodes#

1. Disable Swap:

Code
sudo swapoff -a

2. Load Kernel Modules:

Code
cat <<EOF | sudo tee /etc/modules-load.d/k8s.conf
overlay
br_netfilter
EOF

sudo modprobe overlay
sudo modprobe br_netfilter

3. Set Sysctl Parameters:

Code
cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1
EOF

sudo sysctl --system

4. Install Containerd:

Code
sudo apt-get update
sudo apt-get install -y ca-certificates curl
sudo install -m 0755 -d /etc/apt/keyrings
sudo curl -fsSL https://download.docker.com/linux/ubuntu/gpg -o /etc/apt/keyrings/docker.asc
sudo chmod a+r /etc/apt/keyrings/docker.asc

echo "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.asc] https://download.docker.com/linux/ubuntu $(. /etc/os-release && echo \"$VERSION_CODENAME\") stable" | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null

sudo apt-get update
sudo apt-get install -y containerd.io

containerd config default | sed -e 's/SystemdCgroup = false/SystemdCgroup = true/' -e 's/sandbox_image = "registry.k8s.io\/pause:3.6"/sandbox_image = "registry.k8s.io\/pause:3.9"/' | sudo tee /etc/containerd/config.toml

sudo systemctl restart containerd
sudo systemctl enable containerd
sudo systemctl status containerd

5. Install Kubernetes Components:

Code
sudo apt-get update
sudo apt-get install -y apt-transport-https ca-certificates curl gpg

curl -fsSL https://pkgs.k8s.io/core:/stable:/v1.29/deb/Release.key | sudo gpg --dearmor -o /etc/apt/keyrings/kubernetes-apt-keyring.gpg

echo 'deb [signed-by=/etc/apt/keyrings/kubernetes-apt-keyring.gpg] https://pkgs.k8s.io/core:/stable:/v1.29/deb/ /' | sudo tee /etc/apt/sources.list.d/kubernetes.list

sudo apt-get update
sudo apt-get install -y kubelet kubeadm kubectl
sudo apt-mark hold kubelet kubeadm kubectl

Commands for Master Node Only#

1. Initialize the Cluster:

Code
sudo kubeadm init

2. Configure kubeconfig:

For non-root users (EC2):

Code
mkdir -p "$HOME/.kube"
sudo cp -i /etc/kubernetes/admin.conf "$HOME/.kube/config"
sudo chown "$(id -u):$(id -g)" "$HOME/.kube/config"

For root users (DigitalOcean):

Code
export KUBECONFIG=/etc/kubernetes/admin.conf

3. Install Calico Network Plugin:

Code
kubectl apply -f https://raw.githubusercontent.com/projectcalico/calico/v3.26.0/manifests/calico.yaml

4. Generate Worker Join Command:

Code
kubeadm token create --print-join-command

Commands for Worker Node Only#

1. Reset kubeadm (if needed):

Code
kubeadm reset

2. Join the Cluster:

Code
sudo kubeadm join <master-ip>:6443 --token <token> --discovery-token-ca-cert-hash sha256:<hash> --cri-socket unix:///run/containerd/containerd.sock

Verify the Cluster#

On the master node:

Code
kubectl get nodes

Expected output:

Code
NAME          STATUS   ROLES           AGE   VERSION
master-k8s    Ready    control-plane   XXs   v1.29.x
worker-k8s    Ready    <none>          XXs   v1.29.x

Your Kubernetes cluster is now successfully set up with one control plane and one worker node. This setup forms the foundation for exploring Kubernetes' powerful orchestration capabilities.
